FEATURE
- C ring crown: 16.9 mm (out crown)
- C ring closure dia : 2.5 mm ~ 3.0 mm ( inner size ) egg shape
- C ring wire size : 1.6 mm
- C ring shank height: 8.7 mm
- Standard jaws: 44.5 mm
- Metal magazine: strong & durable
SPECIFICATION
| Body Dimension | L285 x W100 x H200 mm |
|---|---|
| Weight | 1.56 kg |
| Load Capacity | 100 nails |
| Working Pressure | 70 ~ 100 PSI ( 5 ~ 7 Bar ) |
| Packing | 6 PCS/ CTN |
SERIES PRODUCT
KCT-ESC1-15
17GA Air Hog Ring Plier - CMPT to Stanley Bostitch SC73462
KCT-C1-80
15GA/ 16GA Air Hog Ring Plier - CMPT Stanley Bostitch SC7
KCT-C2-80
15GA/ 16GA Air Hog Ring Plier - CMPT Stanley Bostitch SC7E
KCT-SC1-30
16GA Air Hog Ring Plier - CMPT Stanley Bostitch SC760
KCT-SC1-45
16GA Air Hog Ring Plier - CMPT Stanley Bostitch SC761
